Firmness Testing Machine for Edge Paint on Luggage and Bag Straps, and Testing Equipment for Edge Paint Cracking and Peeling

Name: Firmness Testing Machine for Edge Paint on Luggage and Bag Straps and Testing Equipment for Edge Paint Cracking and Peeling
Brand: HUAKAI
Price: 1 USD

Wholesale Firmness Testing Machine for Edge Paint on Luggage and Bag Straps, and Testing Equipment for Edge Paint Cracking and Peeling from china suppliers

Type : Testing Machine

customized support : OEM, OBM

warranty : 1 Year

Application : Abrasion Tester

Voltage : 220 V

Times Setting : 1~99999 (adjustable)

Speed Adjustment : Adjusted by frequency converter

MOQ : 1 piece

Place of Origin : Guangdong, China

Protection Class : IP65

power : 500W

Accuracy Class : High Accuracy

Brand Name : HUAKAI

Accuracy : Horizontal movement stroke: 55±3mm

Adjustment Stroke : Adjusted by eccentric wheel

Price : $1,200-2,800 / piece

Contact Now

Product Overview

Firmness Testing Machine for Edge Paint on Luggage and Bag Straps, and Testing Equipment for Edge Paint Cracking and Peeling

The Edge Paint Fatigue Testing Machine is specifically designed to test the durability and adhesion of edge paint on bag straps. By continuously rubbing and flexing the straps, it simulates long-term usage to determine whether the edge paint cracks or peels off. This machine is ideal for luggage and leather goods manufacturers, quality inspection laboratories, and product development teams.
Functions & Application Areas

Functions:

* Simulates repeated flexing and rubbing of bag straps to evaluate edge paint adhesion and durability.
* Monitors cracking or peeling of edge paint under different loads.
* Supports precise counting and adjustable speed for flexible test settings.
Applications:

* Luggage and leather goods manufacturers for quality assurance.
* Quality inspection laboratories testing edge coating performance.
* Research and development of new bag strap materials and coatings.

Product Paramenters

Parameter	Specification
Control Method	Touchscreen control with user-friendly interface
Vertical Load Options	0.5 kg, 2 kg, 4 kg (one of each)
Counting Range	1–99,999 cycles (adjustable)
Horizontal Movement Stroke	55 ± 3 mm
Horizontal Speed	40 cycles/minute
Travel Adjustment	Eccentric wheel adjustment, front-open design for easy setup
Speed Adjustment	Controlled via frequency converter
Bag Strap Bending Test Device	A. Press head diameter: 10 ± 0.1 mm B. Sensor accuracy: 0.01 kg C. Pressure display: LCD digital display D. Sensor capacity: Max. 10 kg E. Bending block height: 30 ± 1 mm
Weight	55 kg
Power Supply	AC 220V, 50Hz

Products Description

Structure & System Configuration
The HK-562 Edge Paint Fatigue Testing Machine is designed with:
- Touchscreen interface for intuitive control and settings.
- Vertical loading system with three different weight options.
- High-precision pressure sensor and LCD display for accurate readings.
- Adjustable eccentric wheel for easy test travel adjustments.
- Compact and durable structure suitable for factory and laboratory environments.
Applicable International / National Standards
* QB/T1333
* QB/T5246-2018

Details Images

Certifications

Company Profile

Product packaging

Packaging & Shipping

• Internal Protection: Anti-collision foam padding and moisture-proof wrapping are applied to prevent mechanical damage and corrosion during transit. • Marking & Labeling: Each package is clearly labeled with model number, dimensions, weight, and handling instructions for easy identification. • Loading: All packages are reinforced and suitable for forklift handling and container loading.

• Shipping Options: By sea, air, or express courier according to customer preference.
